Description

T series slip ring is a standard slip ring with a through-bore for routing of hydraulic or pneumatic lines or driver shaft. This design features long life, and fiber precious metal brush contact technology realizes ultimate performance in many challenging applications. With aluminum alloy body, double precision roller bearings provide smoother running, lower torque and lower electrical noise.

Model	Voltage	Current Rating	Speed	Insulation Resistance	Dielectric Strength	Electrical Noise	Contact Material	Lead Size/Type	Operate Temp	Storage Temp
VT12
VT25	600V AC/DC	5,10A/Ring	250PRM	1000M Ω @500VDC	AC 600V@60Hz, 60S	70 milliohms MAX @5rpm,50milliamps,6V DC	Precious metal	0.5mm2 Teflon wire	-20℃～+80℃	-30℃～+90℃
VT38	38 0V AC/DC	5,10A/Ring	250PRM	1000M Ω @500VDC	AC 600V@60Hz, 60S	70 milliohms MAX @5rpm,50milliamps,6V DC	Precious metal	0.5mm 2 Teflon wire	-20℃～+80℃	-30℃～+90℃
VT50	38 0V AC/DC	5,10A/Ring	250PRM	1000M Ω @500VDC	AC 600V@60Hz, 60S	70 milliohms MAX @5rpm,50milliamps,6V DC	Precious metal	0.5mm 2 Teflon wire	-20℃～+80℃	-30℃～+90℃
VT60
VT70
VT80
VT90
VT100
VT120
VT145
VT160

through-bore for routing of hydraulic , pneumatic lines or driver shaft;
deliver both power & data signals at the same time;
lower torque and lower electrical noise;
Aluminium alloy body;
Higher speed type for option,up to 2500RPM;
Higher protection class,up to IP68;
Flange for installation and style of exits for lead wires for option.

Rotary tables, test equipments,cable reels;
Robots,processing equipments and rotary sensors;
Exhibit / display equipments;
Medical equipments.

Flange
High Protect class
Wire Exit
Connecter
